Hydraulic Jump Apparatus

Name: Hydraulic Jump Apparatus
Brand: ELSHADDAI ENGINEERING EQUIPMENTS
Price: 165000.0 INR
Availability: InStock

Price 165000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Hydraulic Jump Apparatus Specification

Display Type
Graduated Water Level Scale, Analog Measurement

Temperature Resistance
Upto 50C

Features
Demonstrates formation and profile measurement of Hydraulic Jump; Transparent Flume for Visual Study; Compact and Portable Design

Shape
Rectangular Flume with Integrated Sump Tank

Power Supply
AC Mains - 220/230V, 50 Hz

Control Type
Manual Adjustable Sluice Gate

Glass Type
Transparent Acrylic or Glass Sides in Flume

Accuracy
1 mm Water Level (Scale Graduation)

Type
Hydraulic Jump Apparatus

Dimension (L*W*H)
Approx. 1800mm x 400mm x 1400mm

Equipment Type
Laboratory Apparatus

Equipment Materials
Mild Steel Frame, Acrylic/Glass Flume, Stainless Steel Fittings

Power
Single Phase Motor Pump

Voltage
220V AC

Material
Mild Steel, Acrylic/Glass, Stainless Steel

Application
Fluid Mechanics Laboratory Experiments, Hydraulic Jump Studies

Capacity (Ltr)
80-100 litres

Flow Measurement
Volumetric Tank with Graduated Scale/Rotameter

Flume Length
1000mm to 1500mm

Mobility
Fitted with Castor Wheels

Accessories
Stopwatch, Measuring Scale, Instruction Manual

Drain Valve
Provided for Easy Water Removal

Pump Type
Centrifugal Submersible Water Pump

Water Circulation
Continuous Loop via Sump and Pump

Frame Finish
Powder Coated Anti-Corrosive Surface

Demonstrations Possible
Energy Dissipation, Depth Measurement, Froude Number Calculation

Installation
Plug & Play with Minimal Assembly

Flume Height
250mm to 300mm

Flume Width
100mm to 150mm

About Hydraulic Jump Apparatus

Highlighted as a top-drawer solution for academic and commercial laboratories, the Hydraulic Jump Apparatus with centrifugal submersible pump offers matchless versatility in fluid mechanics experiments. The preeminent design boasts a powder-coated anti-corrosive mild steel frame, a flume with transparent acrylic or glass for enhanced visual studies, and stainless steel fittings. Access precision through a graduated volumetric tank or rotameter for flow measurement, and try now the convenient plug & play installation. Demonstrate energy dissipation, measure Froude numbers, and achieve accurate depth readings with manually adjustable sluice gates in a compact, mobile, and user-friendly setup.

Unmatched Commercial Utility and Material Excellence

The Hydraulic Jump Apparatus is engineered for commercial laboratories, universities, and R&D centers. Its robust mild steel frame, combined with transparent acrylic or glass flumes, ensures enduring performance and visual clarity. As a preeminent tool for studying hydraulic jump phenomena, it offers primary competitive advantages including ease of mobility, high accuracy, and an anti-corrosive finish. Matchless for fluid mechanics studies, it streamlines demonstrations and boosts experiment reliability, supporting top-tier educational and commercial use.

FOB Port, Payment Terms, and Delivery Schedule

Units are shipped from leading Indian ports, with flexible payment terms such as advance, T/T, or L/C. Delivery time is estimated based on order size and customization, typically within 2-4 weeks. Each Hydraulic Jump Apparatus is carefully packed to international standards and delivered efficiently to your specified location. Reliable logistics ensure your product arrives in excellent condition, allowing prompt installation and immediate operational use on delivery.

FAQ's of Hydraulic Jump Apparatus:

Q: How does the Hydraulic Jump Apparatus demonstrate energy dissipation?

A: The apparatus uses a transparent flume and adjustable sluice gate to create and visualize hydraulic jumps, allowing users to observe energy dissipation and study its measurement using flow and depth monitoring accessories.

Q: What are the main advantages of the materials used in this apparatus?

A: High-grade mild steel ensures durability and resistance to corrosion, while transparent acrylic or glass sides provide matchless visualization. Stainless steel fittings guarantee longevity and reliability in laboratory environments.

Q: Where can this Hydraulic Jump Apparatus be used?

A: It is ideal for fluid mechanics laboratories in engineering universities, research centers, and industrial settings requiring precise and observable hydraulic jump studies.

Q: What is the process of installing and operating this apparatus?

A: The apparatus is designed as plug & play, needing minimal assembly. Simply connect to a 220V AC mains power supply, fill the integrated sump, and begin experiments using the manual sluice gate and included measuring tools.

Q: How can water flow and depth be accurately measured during experiments?

A: The volumetric tank with graduated scale or rotameter supplies precise flow rate measurement, while the graduated water level scale provides 1 mm accuracy for depth assessment.
